| Printer Method |
Piezo ink-jet method |
| Dimensions |
1,069 x 617 x 622 mm (42.1 x 24.3 x 24.5 in.) |
| Weight |
62 kg (137 lb.) |
| Media |
Width |
150 to 515 mm (5.91 to 20.2 in.) |
| Thickness |
Max. 1.0 mm (39.3 mil) with liner, for printing Max. 0.4 mm (15.7 mil) with liner and 0.22 mm (8.6 mil) without liner, for cutting |
| Roll outer diameter |
Max. 150 mm (5.9 in.) |
| Roll weight |
Max. 6 kg (13.2 lb.) |
| Core diameter |
76.2 mm (3 in.) or 50.8 mm (2 in.) |
| Printing/cutting width (*1) |
Max. 480 mm (18.89 in.) |
| Ink |
Type |
220 ml cartridge |
| Colors |
Cyan, Magenta, Yellow, Black (BN2-20A) / Cyan, Magenta, Yellow, Black, White (BN2-20) |
| Resolution |
Max. 1,440 dpi |
| Cutting speed |
10 to 150 mm/s (0.39 to 5.9 in/s) |
| Connectivity |
Ethernet (100BASE-TX/1000BASE-T, automatic switching) |
| Power-saving function |
Automatic sleep feature |
| Rated Input |
100-240 Va.c. 50/60 Hz 2.1 A |
| Power consumption |
During operation |
Approx. 185 W |
| Sleep Mode |
Approx. 27 W |
| Acoustic noise level |
During operation |
62 dB (A) or less |
| During standby |
60 dB (A) or less |
| Included items |
Dedicated stands, power cord, media take-up unit, media holders, replacement blade for separating knife, User’s Manual, software (FlexiDESIGNER VersaSTUDIO Edition, VersaWorks, Roland DG Connect) |
