Περιγραφή
Projection Technology / Light Source | 3LCD / UHP Lamp |
Native Resolution / Aspect Ratio | XGA / 4:3 |
Lens Throw Type | Standard |
Brightness (Lumens) Colour Light Output / White Light Output | 4000 |
Light Source Life Maximum (Hours) | 20000 |
Product Weight (Kilograms / Pounds) | 3.1 / 6.8 |
Projection Technology | 3LCD with Micro-Lens Array |
Panel Size | 3 x Sonyu2122 0.63″ |
Native Resolution | XGA |
Pixels | 1024 x 768 |
Aspect Ratio | 4:3 |
Contrast Ratiou00a0 | 50000:1 |
Brightness (Lumens) Colour Light Output / White Light Output | 4000 |
Light Source | UHP Lamp |
Light Source Life Maximum Hours | 20000 |
Maximum Supported Resolution | 3840 x 2160 (4K) @ 30Hz |
Horizontal Sync. Range (KHz) | 15 ~ 100 |
Vertical Sync. Range (Hz) | 48 ~ 85 |
Uniformity (%) | 85 |
Lens | 1.2x |
Lens Zoom Adjustment | Manual |
Optional Lenses | – |
Image Offset (%) | 14 |
Focal Length f (millimeters) | 19.16 ~ 23.02 |
F-Stop | 1.6 ~ 1.76 |
Vertical Lens shift (%) | – |
Horizontal Lens shift (%) | – |
Keystone Adjustment | Automatic/Manual |
Vertical Keystone Correction | ±30° |
Horizontal Keystone Correction | ±30° |
Projection Factor | 1.48 ~ 1.78:1 |
Screen Size | 30″ – 300″ |
Optical Zoom | Manual |
Digital Zoom Demagnification / Magnification | 0.0x ~ 4.0x |
Focus Adjustment | Manual |
Inputs | |
Mini D-sub 15-pin (VGA) | ✅ |
Composite Video | ✅ |
S-Video | – |
HDMIu2122 1.4 | ✅✅ |
HDMIu2122 2.0 | – |
USB-B 2.0 | ✅ |
RJ45 – LAN 10/100/1000 | ✅ |
3.5 mm Stereo Mini Jack | ✅ |
3.5 mm Stereo Mini Jack with Microphone | – |
Outputs | |
Mini D-sub 15-pin (VGA) | ✅ |
3.5 mm Stereo Mini Jack | ✅ |
Powered USB-A for Wireless Dongle | ✅ |
3D Sync | – |
Other | |
RS232 | ✅ |
RJ45 HDBaseT | – |
All Major 3D Formats | – |
USB-B 2.0 for Service | ✅ |
USB-A for Service | – |
Micro USB for Service | – |
Document Reader | ✅ |
Video Player | ✅ |
Photo Viewer | ✅ |
Music Player | ✅ |
12v Screen Trigger | – |
Power Supply | 100 ~ 240 V AC; 50 ~ 60 Hz |
Power Consumption Max (W) | 340 |
Power Consumption Min (W) | 150 |
Power Consumption Network Standby (W) | <2 |
Power Consumption Standby (W) | <0.5 |
Dimensions (W x H x D) (mm / in) | 345 x 261 x 99 / 13.58 x 10.27 x 3.89 |
Product Weight (Kilograms/Pounds) | 3.3 / 7.27 |
Fan Noise Eco/Normal (dB) | 26 ~ 32 |
Audio (W) | 16 |
Operating Temperature (Celsius / Fahrenheit) | 5 ~ 40 / 41 ~ 104 |
Operating Humidity (%) | 20 ~ 80 |
Max Operating Altitude (meters / feet) | 3000 / 9842 |
Storage Temperature (Celsius/Fahrenheit) | -10 ~ 50 / 14 ~ 122 |
Storage Humidity (%) | 20 ~ 80 |
Security | Kensington Lock Portu2122, Security Bar, Keypad Lock, PIN & Timer Functions |
In the Box | Projector, IR Remote Control (no batteries), Power Cord, VGA Cable, Setup Guide |
Safety and Regulatory | CB, CE, EAC, cTUVus, CCC, FCC, UKCA, NOM, PSB, BIS |
Environmental | WEEE, EU RoHS, China RoHS, CEL, CECP |
