Περιγραφή
Image | |
---|---|
Projection Technology | Texas Instruments DLP® |
Panel Size | 0.47″ DMD |
Native Resolution | 4K UHD |
Pixels | 3840 x 2160 |
Aspect Ratio | 16:9 |
Contrast Ratio | 1000000:1 |
Brightness (ISO Lumens) | 4000 |
Light Source | UHP Lamp |
Light Source Life Maximum Hours | 15000 |
Maximum Supported Resolution | 3840 x 2160 |
Horizontal Sync. Range (KHz) | 15 ~ 150 |
Vertical Sync. Range (Hz) | 24 ~ 240 |
Uniformity (%) | 80 |
Optical | |
---|---|
Lens | 1.3x |
Lens Zoom Adjustment | Manual |
Optional Lenses | – |
Image Offset (%) | 115 |
Focal Length (mm) | 12.81 ~ 16.74 |
F-Stop | 2.43 |
Vertical Lens shift (%) | – |
Horizontal Lens shift (%) | – |
Keystone Adjustment | Manual/Automatic |
Vertical Keystone Correction | ± 30° |
Horizontal Keystone Correction | ± 30° |
Projection Factor | 1.21 ~ 2.59:1 |
Projection Distance (Meters/Feet) | 1.0 ~ 8.1 / 3.2 ~ 26.6 |
Optical Zoom | 1.3:1 |
Digital Zoom Demagnification / Magnification | 0.8x ~ 2.0x |
Focus Adjustment | Manual |
Connectivity | |
---|---|
Inputs | 2x HDMI¢ 2.0 (HDCP 2.2), Mini D-sub 15-pin (VGA), 3.5 mm Stereo Mini Jack |
Outputs | 3.5 mm Stereo Mini Jack, USB-A Power 5v 1.5A, S/PDIF Optical Audio |
Networking & Control | RS232 |
Embedded System | – |
3D | Full 3D All Major Formats |
Power | |
---|---|
Power Supply | 100 ~ 240 V AC; 50 ~ 60 Hz |
Power Consumption Max (W) | 300 |
Power Consumption Min (W) | 210 |
Power Consumption Network Standby (W) | – |
Power Consumption Standby (W) | <0.5 |
General | |
---|---|
Product Dimensions (L x W x H) (mm / in) | 313 x 234 x 96.4 / 12.4 x 9.2 x 3.8 |
Product Weight (Kilograms/Pounds) | 3.2/7.0 |
Packaged Dimensions (L x W x H) (mm / in) | 400 x 337 x 168 / 15.7 x 13.3 x 6.6 |
Packaged Weight (Kilograms/Pounds) | 4.4 / 9.7 |
Fan Noise (dB) | 27 |
Audio (W) | 1 x 10 |
Operating Temperature (Celsius/Fahrenheit) | 0 ~ 40 / 32 ~ 104 |
Operating Humidity (%) | 10 ~ 80 |
Max Operating Altitude (meters / feet) | 3048 / 10000 |
Storage Temperature (Celsius/Fahrenheit) | -20 ~ 60 / -4 ~ 140 |
Storage Humidity (%) Non-condensing | 10 ~ 80 |
Security | Kensington Security Slot¢, PIN Code Lock & Timer |
Safety and Regulatory | CB, CE, EAC, cTUVus, CCC, FCC, UKCA |
Environmental | WEEE, EU RoHS, China RoHS |
