Roland VersaStudio BN-20A

Παράδοση σε 7 ημέρες

VersaSTUDIOBN-20A Desktop Printer/Cutter

Με το επιτραπέζιο εκτυπωτικό-κοπτικό BN-20A μπορείτε να υλοποιήσετε ένα πλήθος εφαρμογών με την υψηλότερη ποιότητα. Διαθέτει πιεζοηλεκτρική κεφαλή εκτύπωσης που εκτυπώνει μέχρι 1440 dpi και παρέχει εκτυπώσεις εξαιρετικής ποιότητας με ομαλές διαβαθμίσεις και μεγάλο βάθος χρωμάτων, ιδανικές για φωτογραφίες και vector γραφικά.





Προϊόντα που σας ενδιαφέρουν

Περιγραφή

Model BN-20  BN-20A
Printing technology Piezoelectric inkjet
Media Width *1 150 to 515 mm (5.9 to 20.3 in.)
Thickness Max. 1.0 mm (39 mil) with liner, for printing
Max. 0.4 mm (16 mil) with liner and 0.22 mm (9 mil) without liner, for cutting
Roll weight Max. 6 kg (13.2 lb)
Roll outer diameter Max. 150 mm (5.9 in.)
Core diameter 76.2 mm (3 in.) or 50.8 mm (2 in.)
Printing/cutting width *2 Max. 480 mm (18.9 in.)
Ink Type and capacity ECO-SOL MAX/ MAX2/ MAX 3, 220 cc cartridges  ECO-SOL MAX3, 220 cc cartridges
Colours 5 colours (Cyan, Magenta, Yellow, Black, Metallic Silver or White)  4 colours (Cyan, Magenta, Yellow, Black)
Printing resolution (dots per inch) Max. 1440 dpi
Cutting blade Type Roland CAMM-1 series compatible
Blade Offset 0.25 mm (9 mil)
Cutting speed 10 to 150 mm/s
Blade force 30 to 300 gf
Software resolution (when cutting) 0.025 mm/step
Distance accuracy (when printing) *3,*4 Error of less than ±0.3% of distance travelled, or ±0.3 mm, whichever is greater
Distance accuracy (when cutting) *3,*5 Error of less than ±0.4% of distance travelled, or ±0.3 mm, whichever is greater
Repetition accuracy (When cutting) *3,*6 ±0.1 mm or less
Alignment accuracy for printing and cutting *3,*7 ±0.5 mm or less
Alignment accuracy for printing and cutting when reloading media *3,*8 Error of less than ±0.5% of distance travelled, or ±3 mm, whichever is greater
Print heater *9 Temperature: 35°C (95°F)
Connectivity USB (compliant with Universal Serial Bus Specification Revision 2.0)
Power-saving function Automatic sleep feature
Power requirements AC 100 to 240 V ±10 %, 1.5 A, 50 / 60 HZ
Power consumption During operation Approx. 90 W
Sleep mode Approx. 5.5 W
Acoustic noise level During operation 62 dB (A) or less
During standby 42 dB (A) or less
Dimensions/Weight 1009 (W) x 582 (D) x 293 (H) mm (39.7 x 23 x 11.5 in.) / 36 kg (79.4 lbs)
Environment Power on *10 Temperature: 20 to 32°C (68 to 90°F), humidity: 35 to 80%RH (no condensation)
Power off Temperature: 5 to 40°C (41 to 104°F), humidity: 20 to 80%RH (no condensation)
Included Items Roland VersaWorks 6 RIP Software, power cable, USB cable, blade, blade holder, User’s Manual, etc.

BN2-20A

Printer/Cutterr

MAX. MEDIA WIDTH

20″

INK CONFIGURATIONS

CMYK

POPULAR APPLICATIONS

Apparel
Decals and Labels
Small Signs and Posters
Art and Photography



Επιπλέον πληροφορίες

Brand

67713|Roland VersaStudio BN-20A
